TP-Link RE220BE BE3600 Dual-Band Wi-Fi 7 Range Extender – EasyMesh Compatible

Extend Next-Generation Wi-Fi into Every Corner.

The TP-Link RE220BE BE3600 Dual-Band Wi-Fi 7 Range Extender expands fast, reliable wireless coverage into areas affected by weak signals or Wi-Fi dead zones. Delivering combined wireless speeds up to 3.6Gbps across the 5.0GHz and 2.4GHz bands, it supports demanding streaming, gaming, video conferencing and everyday connected devices. Wi-Fi 7 technologies including Multi-Link Operation, 4K-QAM, Multi-RU and 160MHz channel bandwidth help improve throughput, reduce latency and increase connection reliability with compatible devices. EasyMesh compatibility enables seamless whole-home mesh networking with a compatible router, while the Gigabit Ethernet port provides wired connectivity or supports Access Point mode. Setup and network management are simplified through WPS or the TP-Link Tether app.

FEATURES

• BE3600 Dual-Band Wi-Fi 7 – Delivers combined wireless speeds up to 3.6Gbps for fast, responsive home or office connectivity
• Up to 2882Mbps on 5.0GHz – Supports high-bandwidth activities including 4K and 8K streaming, gaming and large file transfers
• Up to 688Mbps on 2.4GHz – Provides reliable connectivity and broader coverage for everyday and smart home devices
• Multi-Link Operation – Uses multiple wireless links to help improve throughput, reduce latency and increase connection reliability
• 160MHz Channel Bandwidth – Enables greater data capacity on the 5.0GHz band with compatible devices
• 4K-QAM and Multi-RU – Improve wireless transmission efficiency and network capacity
• EasyMesh Compatible – Works with compatible EasyMesh routers and extenders to create seamless whole-home Wi-Fi
• Smart Roaming – Helps compatible devices remain connected while moving between coverage areas
• Two External Antennas – Extend reliable Wi-Fi coverage into hard-to-reach areas
• Gigabit Ethernet Port – Provides a high-speed wired connection for computers, smart TVs, gaming consoles and other devices
• Range Extender and Access Point Modes – Extends an existing wireless network or converts a wired connection into Wi-Fi
• Simple WPS Setup – Connects to a compatible router at the press of a button
• TP-Link Tether App Support – Simplifies setup, monitoring and network management from a compatible mobile device
• Broad Compatibility – Works with devices using current and previous Wi-Fi generations

SPECIFICATIONS

WIRELESS

• Wi-Fi Class: BE3600
• Wireless Standard: Wi-Fi 7
• 5.0GHz Standards: IEEE 802.11be/ax/ac/n/a
• 2.4GHz Standards: IEEE 802.11be/ax/n/b/g
• Frequency Bands: 2.4GHz and 5.0GHz
• Maximum Combined Wireless Speed: Up to 3.6Gbps
• 5.0GHz Signal Rate: Up to 2882Mbps
• 2.4GHz Signal Rate: Up to 688Mbps
• Channel Bandwidth: Up to 160MHz
• Advanced Technologies: Multi-Link Operation, 4K-QAM and Multi-RU
• Wireless Security: WPA/WPA2-PSK and WPA2/WPA3
• Mesh Technology: EasyMesh Compatible
• Working Modes: Range Extender / Access Point
• Wireless Functions: LED Control, Access Control, Power Schedule and Wi-Fi Coverage Control

HARDWARE

• Ethernet Interface: 1× Gigabit Ethernet Port
• Antennas: 2× External Antennas
• Buttons: WPS and Reset
• Input Power: 100~240V AC, 50/60Hz, 0.3A
• Maximum Power Consumption: 15W
• Dimensions (W × D × H): 97 × 46 × 158mm

MANAGEMENT

• Setup Methods: WPS, Web Interface or TP-Link Tether App
• Mobile App: TP-Link Tether for Android and iOS
• Supported Browsers: Internet Explorer, Firefox, Chrome, Safari or another JavaScript-enabled browser

ENVIRONMENT

• Operating Temperature: 0~40°C
• Storage Temperature: -40~70°C
• Operating Humidity: 10~90% Non-Condensing
• Storage Humidity: 5~90% Non-Condensing
